FRONT WHEEL

REAR WHEEL & FINAL DRIVE FOR TRIUMPH TIGER 800 XC

TYRES - VALVES & BALANCE WEIGHTS

(1) T2014400

WHEEL ASSY, REAR, 4.25 X 17

(1) T2016700

WHEEL ASSY, REAR, 4.25 X 17

(2) T2014402

HUB ASSY, REAR

(2) T2016702

HUB ASSY, REAR WHEEL

(3) T2003515

SPACER, WHEEL, 20 127.2

(3) T2010625

SPACER, WHEEL, INTERNAL

(4) T3800703

BEARING, BALL, 20 47 14

(4) T3800703

BEARING, BALL, 20 47 14

(5) T3600701

OIL SEAL, DC 28 47 7

(6) T3500085

CIRCLIP, INT DIA 47

(6) T3500402

CIRCLIP, INT DIA 47

(7) T2014401

RIM, ALUMINIUM, 4.25 X 17"

(7) T2016701

RIM, ALUMINIUM, 4.25 X 17"

(8) T2014404

SPOKE, WIRE, 200MM

(8) T2016824

SPOKE, STEEL

(9) T2005003

NIPPLE, STEEL, SPOKE

(9) T2006103

NIPPLE, STEEL, SPOKE

(10) T2010601

SPROCKET CARR'R ASSY, GRAPHITE

(11) T3800029

BEARING BALL, 25 52 15

(12) T3600073

OIL SEAL, 35 52 6

(13) T3500203

CIRCLIP, INT, 52 X 2

(14) T2012144

STUD, SPROCKET CARRIER

(15) T2010630

BEARING, RING

(16) T2010492

SPACER, STEPPED

(17) T2010650

CUSH DRIVE RUBBER

(18) T2010647

SPACER TUBE, 35 X 20 X 12.5

(19) T2012048

TOP HAT SPACER, 22.4 LONG

(20) T2015060

REAR WHEEL SPINDLE

(21) T3350118

LOCKNUT, PLAIN, M18

(22) T3555035

WASHER, 19 X 34 X 3

(23) T2010226

CHAIN ADJUSTER BLOCK, LH

(23) T2010700

CHAIN ADJUSTER BLOCK, LH

(24) T2010338

CHAIN ADJUSTER BLOCK, RH

(24) T2010800

CHAIN ADJUSTER BLOCK, RH

(25) T3350250

LOCKNUT, FLANGED, M10

(26) T2010535

SPROCKET, REAR, 47T

(26) T2010553

SPROCKET, REAR, 50T

(27) T2011470

CHAIN, FINAL DRIVE, 525, 124L

(27) T2015075

FINAL DRIVE CHAIN, 122L

(27) T2017255

525 CHAIN,122L, SPLIT, SPARES

(27) T2017265

525 CHAIN,124L, SPLIT, SPARES

(28) T2017025

CHAIN & SPROCKET MUTIPACK (5)

(28) T2017134

CHAIN & SPROCKET MULTIPACK (10)

(28) T2017260

CHAIN & SPROCKET KIT, 124/50/16

(28) T2017333

CHAIN & SPROCKET KIT, 122/47/16

	Part number	Description	Qty
# 1	T2014400	WHEEL ASSY, REAR, 4.25 X 17	£822,37
# 1	T2016700	WHEEL ASSY, REAR, 4.25 X 17	£893,88
# 2	T2014402	HUB ASSY, REAR	£397,19
# 2	T2016702	HUB ASSY, REAR WHEEL	£397,19
# 3	T2003515	SPACER, WHEEL, 20 127.2	£20,23
# 3	T2010625	SPACER, WHEEL, INTERNAL	£19,55
# 4	T3800703	BEARING, BALL, 20 47 14	£29,92
# 5	T3600701	OIL SEAL, DC 28 47 7	£14,71
# 6	T3500085	CIRCLIP, INT DIA 47	£3,10
# 6	T3500402	CIRCLIP, INT DIA 47	£4,85
# 7	T2014401	RIM, ALUMINIUM, 4.25 X 17"	£440,63
# 7	T2016701	RIM, ALUMINIUM, 4.25 X 17"	£440,63
# 8	T2014404	SPOKE, WIRE, 200MM	£3,97
# 8	T2016824	SPOKE, STEEL	£3,97
# 9	T2005003	NIPPLE, STEEL, SPOKE	£4,18
# 9	T2006103	NIPPLE, STEEL, SPOKE	£4,18
# 10	T2010601	SPROCKET CARR'R ASSY, GRAPHITE	£428,23
# 11	T3800029	BEARING BALL, 25 52 15	£10,14
# 12	T3600073	OIL SEAL, 35 52 6	£14,27
# 13	T3500203	CIRCLIP, INT, 52 X 2	£10,49
# 14	T2012144	STUD, SPROCKET CARRIER	£4,98
# 15	T2010630	BEARING, RING	£35,38
# 16	T2010492	SPACER, STEPPED	£12,66
# 17	T2010650	CUSH DRIVE RUBBER	£58,96
# 18	T2010647	SPACER TUBE, 35 X 20 X 12.5	£5,28
# 19	T2012048	TOP HAT SPACER, 22.4 LONG	£7,40
# 20	T2015060	REAR WHEEL SPINDLE	£63,30
# 21	T3350118	LOCKNUT, PLAIN, M18	£7,56
# 22	T3555035	WASHER, 19 X 34 X 3	£0,85
# 23	T2010700	CHAIN ADJUSTER BLOCK, LH	£28,93
# 23	T2010226	CHAIN ADJUSTER BLOCK, LH	Not available	£0,00
# 24	T2010338	CHAIN ADJUSTER BLOCK, RH	£27,95
# 24	T2010800	CHAIN ADJUSTER BLOCK, RH	£28,93
# 25	T3350250	LOCKNUT, FLANGED, M10	£2,92
# 26	T2010535	SPROCKET, REAR, 47T	£33,48
# 26	T2010553	SPROCKET, REAR, 50T	£33,48
# 27	T2011470	CHAIN, FINAL DRIVE, 525, 124L	£176,33
# 27	T2015075	FINAL DRIVE CHAIN, 122L	£175,21
# 27	T2017255	525 CHAIN, 122L, SPLIT, SPARES	£120,52
# 27	T2017265	525 CHAIN, 124L, SPLIT, SPARES	£122,76
# 28	T2017025	CHAIN & SPROCKET MUTIPACK (5)	£819,77
# 28	T2017134	CHAIN & SPROCKET MULTIPACK (10)	£1 639,54
# 28	T2017260	CHAIN & SPROCKET KIT, 124/50/16	£163,96
# 28	T2017333	CHAIN & SPROCKET KIT, 122/47/16	£170,74

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the REAR WHEEL & FINAL DRIVE of your Triumph Tiger 800 XC of 800. Let us know if you have any questions.
