Parts diagram

FRONT FORKS & YOKES

HANDLEBARS & SWITCHES FOR TRIUMPH TIGER 800

AIRBOX

(1) T2049750

UPPER YOKE ASSY

(2) T3050324

SCREW, CAP/HD, M8 X 1.25 X 35, SLV

(2) T3050324

SCREW, CAP/HD, M8 X 1.25 X 35, SLV

(3) T2040442

NUT, UPPER YOKE

(4) T2040827

LOWER HANDLEBAR CLAMP

(5) T2040826

CLAMP, HANDLEBAR, UPPER

(6) T3050323

SCREW, CAP/HD, M8 X 30, SLV

(7) T3050153

SCREW, CAP/HD, M10 X 60

(8) T2041007

HANDLEBAR, TUBULAR, TAPERED

(9) T2041849

BAR END WEIGHT

(9) T2041849

BAR END WEIGHT

(10) T3330931

SCREW, CSK, M6 X 20. SLV

(10) T3330931

SCREW, CSK, M6 X 20. SLV

(11) T2040254

HANDLEBAR GRIP, RH

(12) T2040740

HANDLEBAR GRIP, LH

(13) T2504519

SWITCH ASSY, LIGHTS ON, LH

(14) T3331810

SCREW, M5 X 40

(15) T3331790

SCREW, M5 X 30

(16) T2049255

SWITCH ASSY, HANDLEBAR, RH

(17) T3331800

SCREW, M5 X 22

(18) T2040252

THROTTLE ACTUATOR, TWIN CABLE

(19) T2049139

THROTTLE CABLE, TWIN

(20) T3700212

BAND, RUBBER

(20) T3700212

BAND, RUBBER

(21) T2060019

MIRROR ASSY, LH

(22) T2060018

MIRROR ASSY, RH

(23) T3551551

WASHER, 27.5 X 35 X 0.5

	Part number	Description	Qty
# 1	T2049750	UPPER YOKE ASSY	£188,32
# 2	T3050324	SCREW, CAP/HD, M8 X 1.25 X 35, SLV	£3,10
# 3	T2040442	NUT, UPPER YOKE	£16,38
# 4	T2040827	LOWER HANDLEBAR CLAMP	£31,18
# 5	T2040826	CLAMP, HANDLEBAR, UPPER	Not available	£0,00
# 6	T3050323	SCREW, CAP/HD, M8 X 30, SLV	£3,10
# 7	T3050153	SCREW, CAP/HD, M10 X 60	£4,85
# 8	T2041007	HANDLEBAR, TUBULAR, TAPERED	£120,38
# 9	T2041849	BAR END WEIGHT	£21,97
# 10	T3330931	SCREW, CSK, M6 X 20. SLV	£4,72
# 11	T2040254	HANDLEBAR GRIP, RH	£11,84
# 12	T2040740	HANDLEBAR GRIP, LH	£11,84
# 13	T2504519	SWITCH ASSY, LIGHTS ON, LH	£219,42
# 14	T3331810	SCREW, M5 X 40	Not available	£0,00
# 15	T3331790	SCREW, M5 X 30	£0,58
# 16	T2049255	SWITCH ASSY, HANDLEBAR, RH	£159,91
# 17	T3331800	SCREW, M5 X 22	£0,80
# 18	T2040252	THROTTLE ACTUATOR, TWIN CABLE	£42,20
# 19	T2049139	THROTTLE CABLE, TWIN	£36,83
# 20	T3700212	BAND, RUBBER	£2,29
# 21	T2060019	MIRROR ASSY, LH	£84,61
# 22	T2060018	MIRROR ASSY, RH	£84,61
# 23	T3551551	WASHER, 27.5 X 35 X 0.5	£1,18

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the HANDLEBARS & SWITCHES of your Triumph Tiger 800 of 800. Let us know if you have any questions.
