REAR BODYWORK & SEAT

SIDE FAIRINGS FOR TRIUMPH DAYTONA 675 R

ABS SYSTEM

(1) T2309573-NW

FAIRING, UPPER, LH

(1) T2309643-NW

FAIRING, UPPER, LH

(1) T2309643-PD

FAIRING, UPPER, LH

(2) T2309574-NW

FAIRING, UPPER, RH

(2) T2309644-NW

FAIRING, UPPER, RH

(2) T2309644-PD

FAIRING, UPPER, RH

(3) T2309590-MS

FAIRING, LOWER, LH

(3) T2309590-PG

FAIRING, LOWER, LH

(4) T2309591-MS

FAIRING, LOWER, RH

(4) T2309591-PG

FAIRING, LOWER, RH

(5) T2309457

INFILL, FAIRING, LH

(6) T2309460

INFILL, FAIRING, RH

(7) T3350129

NUT, CAPTIVE, M5

(7) T3350129

NUT, CAPTIVE, M5

(7) T3350129

NUT, CAPTIVE, M5

(7) T3350129

NUT, CAPTIVE, M5

(7) T3350129

NUT, CAPTIVE, M5

(8) T3330943

SCREW, BUT/HD, M5 X 14, SLV

(8) T3330943

SCREW, BUT/HD, M5 X 14, SLV

(9) T3331436

SCREW, S/TAP, PAN, TORX, 4 X 11, PT

(9) T3331436

SCREW, S/TAP, PAN, TORX, 4 X 11, PT

(9) T3331436

SCREW, S/TAP, PAN, TORX, 4 X 11, PT

(9) T3331436

SCREW, S/TAP, PAN, TORX, 4 X 11, PT

(10) T2309461

INFILL, RADIATOR, LH

(11) T2309462

INFILL, RADIATOR, RH

(12) T2309472

INFILL, RADIATOR, LOWER

(13) T3701170

PLASTIC RIVET, SCREW TYPE

(13) T3701170

PLASTIC RIVET, SCREW TYPE

(13) T3701170

PLASTIC RIVET, SCREW TYPE

(13) T3701170

PLASTIC RIVET, SCREW TYPE

(13) T3701170

PLASTIC RIVET, SCREW TYPE

(14) T3350123

NUT, CAPTIVE, M5, NON-SECURED

(15) T3331061

BOLT, BUT/HD, M5 X 11, SHLD, SLV

(16) T2309475

BRACKET, FAIRING INFILL, LH

(17) T2309476

BRACKET, FAIRING INFILL, RH

(18) T2309477

BRACKET, FAIRING, LOWER LHF

(19) T2309478

BRACKET, FAIRING, LOWER RHF

(20) T3020029

GROMMET, SIDE PANEL

(20) T3020029

GROMMET, SIDE PANEL

(21) T2309479

BRACKET, FAIRING, LOWER LHR

(22) T2309481

BRACKET, FAIRING, LOWER RHR

(23) T3330726

SCREW, BTN/HD, M6 X 12, SLV

(23) T3330726

SCREW, BTN/HD, M6 X 12, SLV

(23) T3330726

SCREW, BTN/HD, M6 X 12, SLV

(23) T3330726

SCREW, BTN/HD, M6 X 12, SLV

(24) T3350111

NUT, CAPTIVE, M6

(24) T3350111

NUT, CAPTIVE, M6

(24) T3350111

NUT, CAPTIVE, M6

(24) T3350111

NUT, CAPTIVE, M6

(25) T3330955

SCREW, BUT/HD, M5 X 14, SLV, ENC

(25) T3330955

SCREW, BUT/HD, M5 X 14, SLV, ENC

(26) T2308424

FINISHER, LHS

(27) T3100020

STUD, M6

(27) T3331042

SCREW, PAN/HD, TX, M6 X 12, ENC

(28) T3701098

FIRTREE, DIA 5 X 18

(29) T3350003

LOCKNUT, FLANGED, M6 X 1.0

(30) T3700108

CLIP, CABLE, 14.3 X 10

(30) T3700182

CLIP, OMEGA, 18MM X 14MM

	Part number	Description	Qty
# 1	T2309573-NW	FAIRING, UPPER, LH	£449,14
# 1	T2309643-NW	FAIRING, UPPER, LH	£449,14
# 1	T2309643-PD	FAIRING, UPPER, LH	£449,14
# 2	T2309574-NW	FAIRING, UPPER, RH	£449,14
# 2	T2309644-NW	FAIRING, UPPER, RH	£449,14
# 2	T2309644-PD	FAIRING, UPPER, RH	£449,14
# 3	T2309590-MS	FAIRING, LOWER, LH	£294,76
# 3	T2309590-PG	FAIRING, LOWER, LH	£294,76
# 4	T2309591-MS	FAIRING, LOWER, RH	£294,76
# 4	T2309591-PG	FAIRING, LOWER, RH	£294,76
# 5	T2309457	INFILL, FAIRING, LH	£40,34
# 6	T2309460	INFILL, FAIRING, RH	£40,34
# 7	T3350129	NUT, CAPTIVE, M5	£2,22
# 8	T3330943	SCREW, BUT/HD, M5 X 14, SLV	£3,23
# 9	T3331436	SCREW, S/TAP, PAN, TORX, 4 X 11, PT	Not available	£0,00
# 10	T2309461	INFILL, RADIATOR, LH	£63,30
# 11	T2309462	INFILL, RADIATOR, RH	£63,30
# 12	T2309472	INFILL, RADIATOR, LOWER	£65,77
# 13	T3701170	PLASTIC RIVET, SCREW TYPE	£0,80
# 14	T3350123	NUT, CAPTIVE, M5, NON-SECURED	£1,61
# 15	T3331061	BOLT, BUT/HD, M5 X 11, SHLD, SLV	£3,28
# 16	T2309475	BRACKET, FAIRING INFILL, LH	£70,19
# 17	T2309476	BRACKET, FAIRING INFILL, RH	£70,19
# 18	T2309477	BRACKET, FAIRING, LOWER LHF	£23,40
# 19	T2309478	BRACKET, FAIRING, LOWER RHF	£13,28
# 20	T3020029	GROMMET, SIDE PANEL	£1,67
# 21	T2309479	BRACKET, FAIRING, LOWER LHR	£13,28
# 22	T2309481	BRACKET, FAIRING, LOWER RHR	£13,28
# 23	T3330726	SCREW, BTN/HD, M6 X 12, SLV	£2,76
# 24	T3350111	NUT, CAPTIVE, M6	£3,23
# 25	T3330955	SCREW, BUT/HD, M5 X 14, SLV, ENC	£5,53
# 26	T2308424	FINISHER, LHS	£26,94
# 27	T3100020	STUD, M6	£1,38
# 27	T3331042	SCREW, PAN/HD, TX, M6 X 12, ENC	£0,92
# 28	T3701098	FIRTREE, DIA 5 X 18	£3,43
# 29	T3350003	LOCKNUT, FLANGED, M6 X 1.0	£0,62
# 30	T3700108	CLIP, CABLE, 14.3 X 10	£2,12
# 30	T3700182	CLIP, OMEGA, 18MM X 14MM	£2,69

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Triumph, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
