HEADLIGHT ASSEMBLY

IGNITION SWITCH & LOCK SET FOR TRIUMPH SPRINT GT

INDICATORS

(1) T2501158

LOCKSET ASSY

(2) T2507401

IGNITION LOCK

(3) T2501195

FILLER CAP ASSY, FUEL TANK

(4) T3050341

SCREW, CAP/HD, M5 X 10, SLV

(5) T3050343

SCREW, CAP/HD, M5 X 30, SLV

(6) T3050342

SCREW, CAP/HD, M5 X 16, SLV

(7) T3330327

BOLT, SHEAR, M6 X 22, ENC

(8) T3550436

WASHER, M6, ELONGATED

(9) T2500691

LOCK, LATCH, STOWAGE BOX

(10) T2500692

LOCK, BARREL SET, LUGGAGE

(11) T2500622

SEAL, FILLER CAP, BREATHER

(12) T2500508

KEY, CUT, BADGED

(12) T2500511

KEY, BLANK, BADGED

(13) T2500514

KEY, CUT, UNBADGED

(13) T2500517

KEY, BLANK, UNBADGED

(14) T2500523

KEY, CUT, ALARM

(14) T2500526

KEY, BLANK, ALARM

(15) T2501445

LOCK ASSY, SEAT

(16) T2500506

SEAT LATCH HOUSING

(17) T2503021

CABLE, SEAT LOCK

(18) T2307377

POP RIVET, DIA 4.8

(19) T3550289

WASHER, 11 X 5.1 X 1.6

(20) T3330184

SCREW, C'SUNK TX, M6 X 25, SLV

(21) T2502052

COVER, SEAT LOCK

(22) T3701170

PLASTIC RIVET, SCREW TYPE

(23) T2507610

CAP, IGNITION SWITCH, SYMBOLS

(24) T2507620

CAP, IGNITION SWITCH, TEXT

	Part number	Description	Qty
# 1	T2501158	LOCKSET ASSY	£415,80
# 2	T2507401	IGNITION LOCK	£165,06
# 3	T2501195	FILLER CAP ASSY, FUEL TANK	£139,02
# 4	T3050341	SCREW, CAP/HD, M5 X 10, SLV	£2,38
# 5	T3050343	SCREW, CAP/HD, M5 X 30, SLV	£2,92
# 6	T3050342	SCREW, CAP/HD, M5 X 16, SLV	£1,87
# 7	T3330327	BOLT, SHEAR, M6 X 22, ENC	£3,43
# 8	T3550436	WASHER, M6, ELONGATED	£2,92
# 9	T2500691	LOCK, LATCH, STOWAGE BOX	£42,20
# 10	T2500692	LOCK, BARREL SET, LUGGAGE	Not available	£0,00
# 11	T2500622	SEAL, FILLER CAP, BREATHER	£4,02
# 12	T2500508	KEY, CUT, BADGED	£47,17
# 12	T2500511	KEY, BLANK, BADGED	£14,27
# 13	T2500514	KEY, CUT, UNBADGED	£47,17
# 13	T2500517	KEY, BLANK, UNBADGED	£14,27
# 14	T2500523	KEY, CUT, ALARM	£47,17
# 14	T2500526	KEY, BLANK, ALARM	£14,27
# 15	T2501445	LOCK ASSY, SEAT	£91,85
# 16	T2500506	SEAT LATCH HOUSING	£21,55
# 17	T2503021	CABLE, SEAT LOCK	£19,74
# 18	T2307377	POP RIVET, DIA 4.8	£0,74
# 19	T3550289	WASHER, 11 X 5.1 X 1.6	£1,49
# 20	T3330184	SCREW, C'SUNK TX, M6 X 25, SLV	£0,85
# 21	T2502052	COVER, SEAT LOCK	£11,80
# 22	T3701170	PLASTIC RIVET, SCREW TYPE	£0,80
# 23	T2507610	CAP, IGNITION SWITCH, SYMBOLS	£11,75
# 24	T2507620	CAP, IGNITION SWITCH, TEXT	£11,75

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the IGNITION SWITCH & LOCK SET of your Triumph SPRINT GT of Sprint-GT. Let us know if you have any questions.
