MAIN FRAME ASSEMBLY - FROM 914973 ALL EXCEPT BR & IN - FROM 917475 BR & IN ONLY

MAIN FRAME ASSEMBLY UP TO 914972 - ALL EXCEPT BR & IN - UP TO 917474 - BR & IN ONLY FOR TRIUMPH STREET TWIN

MUDGUARDS

(1) T2071987

FRAME ASSY, CANADA

(1) T2071988

FRAME ASSY, AUSTRALIA

(1) T2071989

FRAME ASSY, WORLD

(1) T2071990

FRAME ASSY, AMERICAS

(1) T2072049

FRAME ASSY, SPARES, A2

(2) T2071980

ADJUSTER, FRAME, M12

(2) T2071980

ADJUSTER, FRAME, M12

(3) T2051010

SWINGARM PIVOT ADJUSTER

(4) T2071085

CRADLE ASSY, LH

(5) T2071099

CRADLE ASSY, RH

(6) T2074560

CYLINDER HEAD MOUNT, REAR

(7) T3205486

BOLT, HHF, LGHTD, M8 X 45, SLV

(8) T3150316

BOLT, HHF, M12 X 70, SILVER

(9) T3334675

BOLT, HHF, M12 X 240, SLV

(9) T3334675

BOLT, HHF, M12 X 240, SLV

(10) T3501795

WASHER, M12, OD26, HARDENED, SLV

(10) T3501795

WASHER, M12, OD26, HARDENED, SLV

(10) T3501795

WASHER, M12, OD26, HARDENED, SLV

(10) T3501795

WASHER, M12, OD26, HARDENED, SLV

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(12) T3050227

SCREW, CAP/HD, M10 X 1.25 X 35, SLV

(12) T3050227

SCREW, CAP/HD, M10 X 1.25 X 35, SLV

(12) T3050227

SCREW, CAP/HD, M10 X 1.25 X 35, SLV

(12) T3050227

SCREW, CAP/HD, M10 X 1.25 X 35, SLV

(13) T3350250

LOCKNUT, FLANGED, M10

(13) T3350250

LOCKNUT, FLANGED, M10

(13) T3350250

LOCKNUT, FLANGED, M10

(14) T2075055

BRACKET, M10

(15) T3450060

CAP

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(18) T3450299

FIRTREE, M6

(19) T2072119

SPACER, 13 X 24 X 29

(20) T2070387

BUNG, RUBBER, OVAL

(21) T3151024

BOLT, HHF, M12 X 75, 10,9, SLV

(21) T3151024

BOLT, HHF, M12 X 75, 10,9, SLV

(22) T3151021

BOLT, HHF, M12 X 55, 10.9, SLV

(22) T3151021

BOLT, HHF, M12 X 55, 10.9, SLV

(23) T2074269

COVER, SWINGARM PIVOT

(24) T2073980

FUEL TANK PROTECTION PAD

(25) T2081885

RUBBER PAD, SIDESTAND

(25) T2084848

RUBBER PAD, SIDESTAND

(26) T2071077

MOULDING, EDGE, VIN LABEL

(27) T3350003

LOCKNUT, FLANGED, M6 X 1.0

(28) T3013344

FLANGE SLEEVE, 6.4 X 8.8.X.7.5

(29) T3330342

SCREW, PAN/HD, TX, M6 X 35, SLV

	Part number	Description	Qty
# 1	T2071987	FRAME ASSY, CANADA	£2 060,39
# 1	T2071988	FRAME ASSY, AUSTRALIA	£2 060,39
# 1	T2071989	FRAME ASSY, WORLD	£2 060,39
# 1	T2071990	FRAME ASSY, AMERICAS	£2 060,39
# 1	T2072049	FRAME ASSY, SPARES, A2	£2 060,39
# 2	T2071980	ADJUSTER, FRAME, M12	£6,40
# 3	T2051010	SWINGARM PIVOT ADJUSTER	£15,95
# 4	T2071085	CRADLE ASSY, LH	£175,03
# 5	T2071099	CRADLE ASSY, RH	£175,03
# 6	T2074560	CYLINDER HEAD MOUNT, REAR	Not available	£0,00
# 7	T3205486	BOLT, HHF, LGHTD, M8 X 45, SLV	Not available	£0,00
# 8	T3150316	BOLT, HHF, M12 X 70, SILVER	£8,57
# 9	T3334675	BOLT, HHF, M12 X 240, SLV	£4,54
# 10	T3501795	WASHER, M12, OD26, HARDENED, SLV	£1,49
# 11	T3350234	LOCKNUT, FLGD, M12 X 1.25	£3,97
# 12	T3050227	SCREW, CAP/HD, M10 X 1.25 X 35, SLV	Not available	£0,00
# 13	T3350250	LOCKNUT, FLANGED, M10	£2,92
# 14	T2075055	BRACKET, M10	£9,86
# 15	T3450060	CAP	£0,92
# 16	T3350219	THREADED INSERT	£2,17
# 18	T3450299	FIRTREE, M6	£2,17
# 19	T2072119	SPACER, 13 X 24 X 29	£4,85
# 20	T2070387	BUNG, RUBBER, OVAL	£2,06
# 21	T3151024	BOLT, HHF, M12 X 75, 10, 9, SLV	£4,18
# 22	T3151021	BOLT, HHF, M12 X 55, 10.9, SLV	£4,02
# 23	T2074269	COVER, SWINGARM PIVOT	£27,86
# 24	T2073980	FUEL TANK PROTECTION PAD	£16,07
# 25	T2081885	RUBBER PAD, SIDESTAND	£1,99
# 25	T2084848	RUBBER PAD, SIDESTAND	£1,99
# 26	T2071077	MOULDING, EDGE, VIN LABEL	£10,19
# 27	T3350003	LOCKNUT, FLANGED, M6 X 1.0	£0,62
# 28	T3013344	FLANGE SLEEVE, 6.4 X 8.8.X.7.5	£4,54
# 29	T3330342	SCREW, PAN/HD, TX, M6 X 35, SLV	£1,13

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the MAIN FRAME ASSEMBLY UP TO 914972 - ALL EXCEPT BR & IN - UP TO 917474 - BR & IN ONLY of your Triumph STREET TWIN of Street-Twin. Let us know if you have any questions.
