CRANKCASE & FITTINGS FOR TRIUMPH TIGER EXPLORER XRX

CRANKCASE BOLTS

Item numbers

CRANKCASE ASSEMBLY, SPARES, CRINKLE BLACK

T1162777

£3 837,22

Unit Price Incl. Tax

PLUG, PTF-SAE SHORT, 3/8-18, ENC

T3450000

£4,63

Unit Price Incl. Tax

PLUG, NPSI 3/8 DRYSEAL

T3450005

£4,63

Unit Price Incl. Tax

PLUG, DIA 14, ALUM

T3450091

£1,72

Unit Price Incl. Tax

BEARING, BALL, 6306R

T3800165

£27,72

Unit Price Incl. Tax

BEARING NEEDLE 25 X 32 X 12

T3800203

Not available

SIGHT GLASS

T1261049

£12,02

Unit Price Incl. Tax

CIRCLIP, INT DIA 81.4 X 1.2

T3500078

£0,97

Unit Price Incl. Tax

WASHER, CU, OD12.5 X ID6.4

T3550542

£0,67

Unit Price Incl. Tax

BOLT, HHF, LGHTD, M6 X 12, SLV

T3205062

£2,92

Unit Price Incl. Tax

BUSH, 10 X 12 X 8

T1222207

£3,95

Unit Price Incl. Tax

PIPE, GEARBOX, OIL FEED SPRAY

T1210288

£20,94

Unit Price Incl. Tax

O RING, ID 9.1 X 1.6, VITON

T3600143

£1,45

Unit Price Incl. Tax

O RING, 10.1 DIA X 1.6

T3600252

£1,97

Unit Price Incl. Tax

O RING, ID 5.6 X 2.3

T3600109

£3,68

Unit Price Incl. Tax

DOWEL, HOLLOW, 10 X 14

T3000102

£1,25

Unit Price Incl. Tax

SLEEVE ASSY, NEEDLE BEARING

T1180156

£44,32

Unit Price Incl. Tax

PLATE, OIL RETAINER

T1160217

£2,99

Unit Price Incl. Tax

GASKET, OIL RETAINER PLATE

T1160218

£2,30

Unit Price Incl. Tax

SCREW, PAN/HD, TX, M6 X 12, ENC

T3331042

£0,97

Unit Price Incl. Tax

PLUG, FACE SEAL, M16 X 1.5

T3450119

£4,75

Unit Price Incl. Tax

O RING, 16 X 2

T3600191

£2,63

Unit Price Incl. Tax

PLATE, RETAINER, BEARING, INPUT

T1182203

£3,37

Unit Price Incl. Tax

SCREW, PAN/HD, TX, M6 X 12, ENC

T3331042

£0,97

Unit Price Incl. Tax

WASHER, 6.4 X 16 X 2

T3555012

£2,86

Unit Price Incl. Tax

SCREW, PAN/HD, TX, M6 X 12, ENC

T3331042

£0,97

Unit Price Incl. Tax

DOWEL, HOLLOW, 8 X 14

T3000101

£2,70

Unit Price Incl. Tax

MAIN BEARING, GROOVED, WHITE

T1161450

£11,35

Unit Price Incl. Tax

MAIN BEARING, GROOVED, GREEN

T1161453

£11,35

Unit Price Incl. Tax

MAIN BEARING, GROOVED, RED

T1161451

£11,35

Unit Price Incl. Tax

MAIN BEARING, GROOVED, BLUE

T1161452

£11,35

Unit Price Incl. Tax

FIRTREE, M6

T3450299

£2,30

Unit Price Incl. Tax

BRACKET, CABLE TIDY

T2503147

£2,70

Unit Price Incl. Tax

BAFFLE PLATE, CRANKCASE, BREATHER

T1162201

£2,26

Unit Price Incl. Tax

SCREW, PAN/HD, TX, M6 X 12, ENC

T3331042

£0,97

Unit Price Incl. Tax

GASKET, BREATHER PLATE

T1162202

£8,33

Unit Price Incl. Tax

BUTTON, FIRTREE, M6 X 11

T3450101

£0,97

Unit Price Incl. Tax
