ELECTRICAL EQUIPMENT

ENGINE MANAGEMENT SYSTEM FOR TRIUMPH TIGER 800 XRT

FOG LIGHTS

(1) T1291234

ECM BASE

(1) T1299335

ECM BASE

(2) T1291503

COIL, IGNITION, 1.4 OHM

(3) T1290023

SPARK PLUG

(3) T1290433

SPARK PLUG MULTIPACK (100)

(3) T1290478

SPARK PLUG MULTIPACK (200)

(4) T1290088

SENSOR, AIR TEMPERATURE

(5) T1290975

AIR PRESSURE SENSOR

(6) T3205067

BOLT, HHF, LGHTD, M6 X 25, SLV

(7) T1290975

AIR PRESSURE SENSOR

(8) T3332464

SCREW, S/TAP, THF, 5 X 25

(8) T3332464

SCREW, S/TAP, THF, 5 X 25

(9) T1290660

GEAR POSITION SENSOR

(10) T3205066

BOLT, HHF, LGHTD, M6 X 20, SLV

(11) T3600267

O RING, ID 26.65 X DIA 2.62

(14) T3205064

BOLT, RHHF, DOMED, S/S, M6 X 16, ENC

(15) T2100807

SENSOR, COOLANT TEMP

(16) T3550571

WASHER, CU, OD 16 X ID 12.5

(17) T1292075

HOSE, THROTTLE BODY, CYL 1

(18) T1292076

HOSE, THROTTLE BODY, CYL 2

(19) T1292077

HOSE, THROTTLE BODY, CYL 3

(20) T1290136

HOSE, MAP SENSOR

(21) T1242929

CONNECTOR, 4 WAY

(22) T3700254

HOSE GUIDE

(23) T3700077

CLIP, 10.5 RER OETIKER

(24) T1290139

VR SENSOR IGNITION, V GROMMET

(25) T1290148

BRACKET, CABLE GUIDE, VR SENSOR

(26) T1290147

BRACKET, CABLE GUIDE, VR SENSOR

(27) T3330178

BOLT, RHHF, M5 X 12, ENCAPS

(27) T3330178

BOLT, RHHF, M5 X 12, ENCAPS

(28) T1164500

BLANKING PLUG

(29) T3600085

O-RING, ID 14.6, SD 2.4

(30) T2040811

TWIN CLIP, BRAKE HOSE

(30) T2040811

TWIN CLIP, BRAKE HOSE

(31) T2509323

FLYLEAD, GEAR POSITION SENSOR

	Part number	Description	Qty
# 1	T1291234	ECM BASE	£750,94
# 1	T1299335	ECM BASE	£1 638,40
# 2	T1291503	COIL, IGNITION, 1.4 OHM	£127,84
# 3	T1290023	SPARK PLUG	£10,87
# 3	T1290433	SPARK PLUG MULTIPACK (100)	£1 087,87
# 3	T1290478	SPARK PLUG MULTIPACK (200)	£2 175,74
# 4	T1290088	SENSOR, AIR TEMPERATURE	£45,30
# 5	T1290975	AIR PRESSURE SENSOR	£94,33
# 6	T3205067	BOLT, HHF, LGHTD, M6 X 25, SLV	£1,72
# 7	T1290975	AIR PRESSURE SENSOR	£94,33
# 8	T3332464	SCREW, S/TAP, THF, 5 X 25	£1,43
# 9	T1290660	GEAR POSITION SENSOR	£78,20
# 10	T3205066	BOLT, HHF, LGHTD, M6 X 20, SLV	£2,98
# 11	T3600267	O RING, ID 26.65 X DIA 2.62	£1,00
# 14	T3205064	BOLT, RHHF, DOMED, S/S, M6 X 16, ENC	£2,60
# 15	T2100807	SENSOR, COOLANT TEMP	Not available	£0,00
# 16	T3550571	WASHER, CU, OD 16 X ID 12.5	£0,50
# 17	T1292075	HOSE, THROTTLE BODY, CYL 1	£2,12
# 18	T1292076	HOSE, THROTTLE BODY, CYL 2	£2,12
# 19	T1292077	HOSE, THROTTLE BODY, CYL 3	£2,12
# 20	T1290136	HOSE, MAP SENSOR	£7,81
# 21	T1242929	CONNECTOR, 4 WAY	£7,13
# 22	T3700254	HOSE GUIDE	£4,28
# 23	T3700077	CLIP, 10.5 RER OETIKER	£2,60
# 24	T1290139	VR SENSOR IGNITION, V GROMMET	£73,22
# 25	T1290148	BRACKET, CABLE GUIDE, VR SENSOR	£11,18
# 26	T1290147	BRACKET, CABLE GUIDE, VR SENSOR	£11,18
# 27	T3330178	BOLT, RHHF, M5 X 12, ENCAPS	£3,48
# 28	T1164500	BLANKING PLUG	£1,67
# 29	T3600085	O-RING, ID 14.6, SD 2.4	£2,60
# 30	T2040811	TWIN CLIP, BRAKE HOSE	£1,72
# 31	T2509323	FLYLEAD, GEAR POSITION SENSOR	£14,21

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ENGINE MANAGEMENT SYSTEM of your Triumph Tiger 800 XRT of 800. Let us know if you have any questions.
