FRONT FORKS & YOKES - LOW RIDE HEIGHT VERSION ONLY FOR TRIUMPH TIGER 800 XRX

FRONT FORKS & YOKES   LOW RIDE HEIGHT VERSION ONLY for Triumph Tiger 800 XRX

(1)  T2048272
FRONT FORK ASSY, LH

(2)  T2048277
FRONT FORK ASSY, RH

(3)  T2048177
FORK BOLT

(4)  T2048137
O RING

(5)  T2048179
SEAT RUBBER

(6)  T2048172
OUTER TUBE, BLACK

(7)  T2045094
BUSH, GUIDE, OUTER

(8)  T2046246
SEAL, SPACER

(9)  T2048424
OIL SEAL

(10)  T2046248
STOP RING

(11)  T2041542
DUST SEAL

(12)  T2048418
SPG COLLAR

(13)  T2046166
SPRING SEAT

(14)  T2048144
SPRING

(15)  T2048139
SPG SEAT STOPPER

(16)  T2048143
DAMPER COMP

(17)  T2048174
CENTERING PLATE

(18)  T2045095
BUSH, SLIDE, INNER

(19)  T2048185
RH SLIDE PIPE
(19)  T2048279
LH SLIDE PIPE COMP

(20)  T2042907
SEALING WASHER

(21)  T2046164
CAPSCREW, OIL LOCK

(22)  T2046146
HEX SOCKET BOLT Part information

(23)  T2049768
LOWER YOKE ASSY

(24)  T3050300
SCREW, CAP/HD, M8

(24)  T3050300
SCREW, CAP/HD, M8

(25)  T3450060
CAP

(26)  T2040304
LOCKNUT, M30

(27)  T2041306
WASHER, HEADSTOCK

(28)  T2040301
ADJUSTER NUT, M30, LOWER

(29)  T2046559
COVER, HEADSTOCK BEARING

(30)  T3600234
DUST SEAL, DIA 55

(30)  T3600234
DUST SEAL, DIA 55

(31)  T2046206
BRACKET, MUDGUARD EXTENSION

(31)  T2046206
BRACKET, MUDGUARD EXTENSION

(32)  T3331042
SCREW, PAN/HD, TX, M6 X 12, ENC

(32)  T3331042
SCREW, PAN/HD, TX, M6 X 12, ENC
Part number Description
# 1
T2048272
FRONT FORK ASSY, LH
# 2
T2048277
FRONT FORK ASSY, RH
# 3
T2048177
FORK BOLT
# 4
T2048137
O RING
# 5
T2048179
SEAT RUBBER
# 6
T2048172
OUTER TUBE, BLACK
# 7
T2045094
BUSH, GUIDE, OUTER
# 8
T2046246
SEAL, SPACER
# 9
T2048424
OIL SEAL
# 10
T2046248
STOP RING
# 11
T2041542
DUST SEAL
# 12
T2048418
SPG COLLAR
# 13
T2046166
SPRING SEAT
# 14
T2048144
SPRING
# 15
T2048139
SPG SEAT STOPPER
# 16
T2048143
DAMPER COMP
# 17
T2048174
CENTERING PLATE
# 18
T2045095
BUSH, SLIDE, INNER
# 19
T2048185
RH SLIDE PIPE
# 19
T2048279
LH SLIDE PIPE COMP
# 20
T2042907
SEALING WASHER
# 21
T2046164
CAPSCREW, OIL LOCK
# 22
T2046146
HEX SOCKET BOLT
# 23
T2049768
LOWER YOKE ASSY
# 24
T3050300
SCREW, CAP/HD, M8
# 25
T3450060
CAP
# 26
T2040304
LOCKNUT, M30
# 27
T2041306
WASHER, HEADSTOCK
Contact
# 28
T2040301
ADJUSTER NUT, M30, LOWER
# 29
T2046559
COVER, HEADSTOCK BEARING
# 30
T3600234
DUST SEAL, DIA 55
# 31
T2046206
BRACKET, MUDGUARD EXTENSION
# 32
T3331042
SCREW, PAN/HD, TX, M6 X 12, ENC
Mark the parts and select the numbers you need in the image or the parts list and add them directly to your shopping basket.

Be careful to choose the right amount that you add to your shopping cart.
