CRANKSHAFT - CONNECTING ROD & PISTONS - BONNEVILLE

ELECTRICAL EQUIPMENT BONNEVILLE T100 FOR TRIUMPH BONNEVILLE T100 CARBS

ELECTRICAL EQUIPMENT BONNEVILLE

(1) T2500020

BATTERY,12V, 10 AH

(1) T2502347

BATTERY MULTIPACK (10)

(2) T2501740

BATTERY STRAP

(3) T2500358

KIT, HARNESS, MAIN

(3) T2500361

KIT, HARNESS, MAIN

(3) T2501515

HARNESS, MAIN

(3) T2501550

MAIN HARNESS

(4) T2501305

FUSE, MINI, 5A

(5) T2501310

FUSE, MINI, 10A

(6) T2501315

FUSE, MINI, 15A

(7) T2500805

FUSE, 30A

(8) T2500199

HORN, 420 HZ, CHROME

(9) T3205156

BOLT, HHF, LGHTD, M8 X 18, SLV

(10) T2500531

RELAY, INDICATOR, 2 (4) X 10W

(11) T2501705

RELAY, CHANGEOVER

(12) T2500344

CABLE, 10MM, 1.1M LONG, BK

(13) T2500346

SUBHARNESS, BATTERY, NEGATIVE

(14) T2500347

LEAD, OIL PRESSURE SWITCH

(15) T3700015

CABLE TIE, 185.7 LONG

(16) T3450261

FIRTREE PLUG

(17) T3700072

CABLE CLIP, DIA 15-16MM BK

(18) T3700233

CLIP, BRAKE HOSE

(19) T3701098

FIRTREE, DIA 5 X 18

(20) T3700096

P CLIP, DIA 15.9, PLASTIC, BLK

(21) T3330941

SCREW, BUT/HD, SKT, M5 X 16, SLV

(22) T3701101

CLIP, FIRTREE, MUSHROOM, HD, BLK

(23) T2500339

SUBHARNESS, NEUTRAL

(24) T2501335

FUSEBOX LID

(25) T2500259

RELAY, GROMMET

	Part number	Description	Qty
# 1	T2502347	BATTERY MULTIPACK (10)	£802,02
# 1	T2500020	BATTERY, 12V, 10 AH	Not available	£0,00
# 2	T2501740	BATTERY STRAP	£6,52
# 3	T2500358	KIT, HARNESS, MAIN	£552,35
# 3	T2501550	MAIN HARNESS	£552,35
# 3	T2500361	KIT, HARNESS, MAIN	Not available	£0,00
# 3	T2501515	HARNESS, MAIN	Not available	£0,00
# 4	T2501305	FUSE, MINI, 5A	£3,10
# 5	T2501310	FUSE, MINI, 10A	£3,10
# 6	T2501315	FUSE, MINI, 15A	£3,10
# 7	T2500805	FUSE, 30A	£0,92
# 8	T2500199	HORN, 420 HZ, CHROME	£28,32
# 9	T3205156	BOLT, HHF, LGHTD, M8 X 18, SLV	£1,06
# 10	T2500531	RELAY, INDICATOR, 2 (4) X 10W	£63,30
# 11	T2501705	RELAY, CHANGEOVER	£9,24
# 12	T2500344	CABLE, 10MM, 1.1M LONG, BK	£39,55
# 13	T2500346	SUBHARNESS, BATTERY, NEGATIVE	£18,55
# 14	T2500347	LEAD, OIL PRESSURE SWITCH	£18,18
# 15	T3700015	CABLE TIE, 185.7 LONG	£0,62
# 16	T3450261	FIRTREE PLUG	£1,33
# 17	T3700072	CABLE CLIP, DIA 15-16MM BK	£2,69
# 18	T3700233	CLIP, BRAKE HOSE	£3,85
# 19	T3701098	FIRTREE, DIA 5 X 18	£3,43
# 20	T3700096	P CLIP, DIA 15.9, PLASTIC, BLK	£3,23
# 21	T3330941	SCREW, BUT/HD, SKT, M5 X 16, SLV	£4,42
# 22	T3701101	CLIP, FIRTREE, MUSHROOM, HD, BLK	£1,25
# 23	T2500339	SUBHARNESS, NEUTRAL	£27,52
# 24	T2501335	FUSEBOX LID	£9,91
# 25	T2500259	RELAY, GROMMET	£2,69

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Triumph, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
