TRANSMISSION

COOLING SYSTEM FOR TRIUMPH SPRINT ST

CAM COVER

(1) T2100196

THERMOSTAT HOUSING

(2) T2102131

THERMOSTAT

(3) T3600210

O RING

(4) T2100272

RETAINER

(5) T3331102

BOLT, HHF, M6 X 25, S/S

(6) T3600200

O RING

(7) T3550542

WASHER, CU, OD12.5 X ID6.4

(8) T3150007

BOLT

(9) T2100074

CAP ASSY

(10) T3331043

SCREW, PAN/HD, TX, M6 X 12, SLV

(10) T3331043

SCREW, PAN/HD, TX, M6 X 12, SLV

(10) T3331043

SCREW, PAN/HD, TX, M6 X 12, SLV

(11) T2100185

TANK EXPANSION

(12) T3205066

BOLT, HHF, LGHTD, M6 X 20, SLV

(13) T2100405

ELBOW, ID 8.0 TUBE

(13) T2100405

ELBOW, ID 8.0 TUBE

(14) T3021200

GROMMET, DIA 14X4, PANEL

(14) T3021200

GROMMET, DIA 14X4, PANEL

(14) T3021200

GROMMET, DIA 14X4, PANEL

(15) T2100997

CAP, EXPANSION TANK

(16) T3620320

PIPE, EXPANSION TANK, INTERNAL

(17) T3620300

OVERFLOW PIPE

(17) T3620300

OVERFLOW PIPE

(18) T3700440

CLIP, HOSE, 11-12.5MM

(19) T3700077

CLIP, 10.5 RER OETIKER

(20) T3450035

GROMMET, DIA 8, DIA 12.5, 3

(21) T3660113

RUBBER PAD

(21) T3660113

RUBBER PAD

(22) T2100509

WATER PUMP ASSY

(23) T3600230

SEAL

(24) 3600160-T0301

O RING, WATER PUMP

(25) T3205075

BOLT, HHF, LGHTD, M6 X 65, SLV

(26) T2102127

ELBOW

(26) T2102162

INLET ELBOW

(27) T2100110

HOSE OUTLET

(28) T2102143

GASKET

(28) T3600185

O RING

(29) T3330334

SCREW, TX, PAN/HD, M6 X 16, SLV

(29) T3331234

SCREW, TORX, P/H, M6 X 20, SLV

(30) T2100192

HOSE

(30) T2100192

HOSE

(31) T2100193

HOSE

(32) T2100194

HOSE

(33) T2102392

HOSE BOTTOM

(34) T2102242

HOSE CLIP, 23-25, BRIGHT, SS

(34) T2102242

HOSE CLIP, 23-25, BRIGHT, SS

(34) T2102242

HOSE CLIP, 23-25, BRIGHT, SS

(34) T2102242

HOSE CLIP, 23-25, BRIGHT, SS

(34) T2102242

HOSE CLIP, 23-25, BRIGHT, SS

(34) T2102242

HOSE CLIP, 23-25, BRIGHT, SS

(34) T2102242

HOSE CLIP, 23-25, BRIGHT, SS

(35) T3700171

HOSE CLIP, DIA 14.0

(36) T2102112

HOSE CLIP, 16-27, BRIGHT, SS

(37) T3555004

WASHER, 6.4 X 14 X 1.6

(37) T3555004

WASHER, 6.4 X 14 X 1.6

(38) T2101241

FAN

(39) T2100670

RADIATOR

(40) T2101323

BRACKET

(41) T2101322

BRACKET

(42) T3205083

BOLT, HHF, LGHTD, M6 X 28, SLV

(42) T3205083

BOLT, HHF, LGHTD, M6 X 28, SLV

(43) T3010710

FLANGED SLEEVE, 6.4 X 9.6 X 13.4

(43) T3010710

FLANGED SLEEVE, 6.4 X 9.6 X 13.4

(44) T2100197

MOUNTING BRACKET

(45) T3350012

LOCKNUT, FLGD, M6, BLACK, ZINC

(45) T3350012

LOCKNUT, FLGD, M6, BLACK, ZINC

(45) T3350012

LOCKNUT, FLGD, M6, BLACK, ZINC

(46) T2100807

SENSOR, COOLANT TEMP

(47) T3550571

WASHER, CU, OD 16 X ID 12.5

(48) T3010014

FLANGED SLEEVE, M6, BLACK

(48) T3010014

FLANGED SLEEVE, M6, BLACK

(49) T3020031

GROMMET

(49) T3020031

GROMMET

(50) T3700044

GUIDE, CABLE (WIRE GUIDE)

(51) T3700047

WIRE GUIDE

(52) A9610046

COOLANT, HYBRID OAT, 12 X 1L

	Part number	Description	Qty
# 1	T2100196	THERMOSTAT HOUSING	Not available	£0,00
# 2	T2102131	THERMOSTAT	Not available	£0,00
# 3	T3600210	O RING	£0,92
# 4	T2100272	RETAINER	Not available	£0,00
# 5	T3331102	BOLT, HHF, M6 X 25, S/S	£1,93
# 6	T3600200	O RING	£2,42
# 7	T3550542	WASHER, CU, OD12.5 X ID6.4	£0,66
# 8	T3150007	BOLT	Not available	£0,00
# 9	T2100074	CAP ASSY	£17,38
# 10	T3331043	SCREW, PAN/HD, TX, M6 X 12, SLV	£0,62
# 11	T2100185	TANK EXPANSION	Not available	£0,00
# 12	T3205066	BOLT, HHF, LGHTD, M6 X 20, SLV	£2,98
# 13	T2100405	ELBOW, ID 8.0 TUBE	£0,92
# 14	T3021200	GROMMET, DIA 14X4, PANEL	£2,06
# 15	T2100997	CAP, EXPANSION TANK	£6,22
# 16	T3620320	PIPE, EXPANSION TANK, INTERNAL	£0,92
# 17	T3620300	OVERFLOW PIPE	£8,62
# 18	T3700440	CLIP, HOSE, 11-12.5MM	£3,55
# 19	T3700077	CLIP, 10.5 RER OETIKER	£2,60
# 20	T3450035	GROMMET, DIA 8, DIA 12.5, 3	£1,38
# 21	T3660113	RUBBER PAD	Not available	£0,00
# 22	T2100509	WATER PUMP ASSY	£160,10
# 23	T3600230	SEAL	£3,77
# 24	3600160-T0301	O RING, WATER PUMP	£5,90
# 25	T3205075	BOLT, HHF, LGHTD, M6 X 65, SLV	£2,48
# 26	T2102127	ELBOW	Not available	£0,00
# 26	T2102162	INLET ELBOW	Not available	£0,00
# 27	T2100110	HOSE OUTLET	£15,47
# 28	T2102143	GASKET	£0,92
# 28	T3600185	O RING	£1,72
# 29	T3330334	SCREW, TX, PAN/HD, M6 X 16, SLV	£1,72
# 29	T3331234	SCREW, TORX, P/H, M6 X 20, SLV	£3,48
# 30	T2100192	HOSE	£38,47
# 31	T2100193	HOSE	Not available	£0,00
# 32	T2100194	HOSE	Not available	£0,00
# 33	T2102392	HOSE BOTTOM	£13,97
# 34	T2102242	HOSE CLIP, 23-25, BRIGHT, SS	£5,22
# 35	T3700171	HOSE CLIP, DIA 14.0	£4,54
# 36	T2102112	HOSE CLIP, 16-27, BRIGHT, SS	£3,17
# 37	T3555004	WASHER, 6.4 X 14 X 1.6	£0,92
# 38	T2101241	FAN	£328,92
# 39	T2100670	RADIATOR	£595,78
# 40	T2101323	BRACKET	Not available	£0,00
# 41	T2101322	BRACKET	Not available	£0,00
# 42	T3205083	BOLT, HHF, LGHTD, M6 X 28, SLV	£1,61
# 43	T3010710	FLANGED SLEEVE, 6.4 X 9.6 X 13.4	£2,69
# 44	T2100197	MOUNTING BRACKET	Not available	£0,00
# 45	T3350012	LOCKNUT, FLGD, M6, BLACK, ZINC	£0,74
# 46	T2100807	SENSOR, COOLANT TEMP	Not available	£0,00
# 47	T3550571	WASHER, CU, OD 16 X ID 12.5	£0,50
# 48	T3010014	FLANGED SLEEVE, M6, BLACK	£1,00
# 49	T3020031	GROMMET	£2,06
# 50	T3700044	GUIDE, CABLE (WIRE GUIDE)	£6,46
# 51	T3700047	WIRE GUIDE	£4,85
# 52	A9610046	COOLANT, HYBRID OAT, 12 X 1L	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the COOLING SYSTEM of your Triumph SPRINT ST of Sprint-ST. Let us know if you have any questions.
