FUEL PUMP AND FILTERS

FUEL TANK AND FITTINGS FOR TRIUMPH SPRINT ST

THROTTLES / INJECTORS AND FUEL RAIL

(1) T2400509-CM

FUEL TANK

(1) T2400509-HA

FUEL TANK

(1) T2400509-JM

FUEL TANK

(1) T2400509-PG

FUEL TANK

(2) T2400530

INSULATION

(3) T2400528

FOAM PAD

(4) T2400529

FOAM PAD

(5) T2500468

SEAL, BASE, FUEL FILLER

(6) T2500469

NECK, FUEL FILLER

(7) T2500464

SEAL, FUEL FILLER CAP

(8) T3330790

BOLT

(9) T3010008

FLANGED SLEEVE

(10) T3020090

GROMMET

(11) T3330876

SCREW, C/SUNK, SKT, M6 X 40, SS

(12) T3550344

WASHER, COUNTERSUNK, M6

(13) T3000024

SLEEVE, M6 X 23

(14) T3550061

WASHER, M6X13

(15) 2400042-T0301

FRONT TANK RETENTION RUBBER

(16) T2400526

FUEL LEVEL SENDER

(16) T2402416

FUEL LEVEL SENSOR, CHAMFERED

(17) T2401225

SEAL, FUEL LEVEL SENDER, E25

(18) T3330891

BOLT, RHHF, M5 X 0.8 X 12, S5041

(19) T3020460

GROMMET

(20) 3550063-T0301

WASHER, RUBBER

(20) 3550063-T0301

WASHER, RUBBER

(21) 2400043-T0301

CONNECTOR, OVERFLOW PIPE

(21) 2400043-T0301

CONNECTOR, OVERFLOW PIPE

(22) T4000751

HOSE, TWIN WALL, NBR/CSM 5 X 8

(22) T4000751

HOSE, TWIN WALL, NBR/CSM 5 X 8

(22) T4000751

HOSE, TWIN WALL, NBR/CSM 5 X 8

(23) T2400045

VALVE, ROLL OVER

(24) T2500466

VENT SEAL

(25) T3050342

SCREW, CAP/HD, M5 X 16, SLV

(26) T3050144

SCREW, CAP HD, M5X30, SS

(27) T3050341

SCREW, CAP/HD, M5 X 10, SLV

(28) T2501012

CAP, FUEL FILLER, NON VENTED

(29) T1241054

SEAL, MOUNTING PLATE

(30) T3900132

LABEL, FUEL TANK, FAIRED

(31) T3900154

LABEL, RUNNING IN

(32) T2400201

FLOAT, FUEL LEVEL SENDER

	Part number	Description	Qty
# 1	T2400509-CM	FUEL TANK	Not available	£0,00
# 1	T2400509-HA	FUEL TANK	Not available	£0,00
# 1	T2400509-JM	FUEL TANK	Not available	£0,00
# 1	T2400509-PG	FUEL TANK	Not available	£0,00
# 2	T2400530	INSULATION	£18,91
# 3	T2400528	FOAM PAD	£11,00
# 4	T2400529	FOAM PAD	£11,00
# 5	T2500468	SEAL, BASE, FUEL FILLER	£4,66
# 6	T2500469	NECK, FUEL FILLER	£12,10
# 7	T2500464	SEAL, FUEL FILLER CAP	£5,22
# 8	T3330790	BOLT	Not available	£0,00
# 9	T3010008	FLANGED SLEEVE	£7,56
# 10	T3020090	GROMMET	Not available	£0,00
# 11	T3330876	SCREW, C/SUNK, SKT, M6 X 40, SS	£2,69
# 12	T3550344	WASHER, COUNTERSUNK, M6	£3,36
# 13	T3000024	SLEEVE, M6 X 23	£4,66
# 14	T3550061	WASHER, M6X13	£1,13
# 15	2400042-T0301	FRONT TANK RETENTION RUBBER	£10,03
# 16	T2402416	FUEL LEVEL SENSOR, CHAMFERED	£74,47
# 16	T2400526	FUEL LEVEL SENDER	Not available	£0,00
# 17	T2401225	SEAL, FUEL LEVEL SENDER, E25	£6,76
# 18	T3330891	BOLT, RHHF, M5 X 0.8 X 12, S5041	£2,12
# 19	T3020460	GROMMET	£1,87
# 20	3550063-T0301	WASHER, RUBBER	£0,80
# 21	2400043-T0301	CONNECTOR, OVERFLOW PIPE	£5,28
# 22	T4000751	HOSE, TWIN WALL, NBR/CSM 5 X 8	£3,28
# 23	T2400045	VALVE, ROLL OVER	Not available	£0,00
# 24	T2500466	VENT SEAL	Not available	£0,00
# 25	T3050342	SCREW, CAP/HD, M5 X 16, SLV	£1,87
# 26	T3050144	SCREW, CAP HD, M5X30, SS	£1,49
# 27	T3050341	SCREW, CAP/HD, M5 X 10, SLV	£2,38
# 28	T2501012	CAP, FUEL FILLER, NON VENTED	£139,02
# 29	T1241054	SEAL, MOUNTING PLATE	£39,73
# 30	T3900132	LABEL, FUEL TANK, FAIRED	£3,71
# 31	T3900154	LABEL, RUNNING IN	£1,87
# 32	T2400201	FLOAT, FUEL LEVEL SENDER	Not available	£0,00

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FUEL TANK AND FITTINGS of your Triumph SPRINT ST of Sprint-ST. Let us know if you have any questions.
