FOOT CONTROLS SINGLE SEAT VERSION

MAIN FRAME ASSEMBLY FOR TRIUMPH THRUXTON

MUDGUARDS

(1) T2074761

FRAME ASSY, WORLD

(1) T2074762

FRAME ASSY, AMERICAS

(1) T2074763

FRAME ASSY, AUSTRALIA

(1) T2074764

FRAME ASSY, CANADA

(2) T2071980

ADJUSTER, FRAME, M12

(2) T2071980

ADJUSTER, FRAME, M12

(2) T2071980

ADJUSTER, FRAME, M12

(2) T2071980

ADJUSTER, FRAME, M12

(3) T2051010

SWINGARM PIVOT ADJUSTER

(4) T2071085

CRADLE ASSY, LH

(5) T2071099

CRADLE ASSY, RH

(8) T3150316

BOLT, HHF, M12 X 70, SILVER

(9) T3334675

BOLT, HHF, M12 X 240, SLV

(9) T3334675

BOLT, HHF, M12 X 240, SLV

(10) T3501795

WASHER, M12, OD26, HARDENED, SLV

(10) T3501795

WASHER, M12, OD26, HARDENED, SLV

(10) T3501795

WASHER, M12, OD26, HARDENED, SLV

(10) T3501795

WASHER, M12, OD26, HARDENED, SLV

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(11) T3350234

LOCKNUT, FLGD, M12 X 1.25

(12) T3050227

SCREW, CAP/HD, M10 X 1.25 X 35, SLV

(12) T3050227

SCREW, CAP/HD, M10 X 1.25 X 35, SLV

(12) T3050227

SCREW, CAP/HD, M10 X 1.25 X 35, SLV

(12) T3050227

SCREW, CAP/HD, M10 X 1.25 X 35, SLV

(13) T3350250

LOCKNUT, FLANGED, M10

(13) T3350250

LOCKNUT, FLANGED, M10

(13) T3350250

LOCKNUT, FLANGED, M10

(14) T2075055

BRACKET, M10

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(16) T3350219

THREADED INSERT

(18) T3450299

FIRTREE, M6

(19) T2072119

SPACER, 13 X 24 X 29

(20) T2070387

BUNG, RUBBER, OVAL

(21) T3151142

BOLT, TX, M12 X 75, SLV

(21) T3151142

BOLT, TX, M12 X 75, SLV

(22) T3151141

BOLT, TX, M12 X 55, SLV

(22) T3151141

BOLT, TX, M12 X 55, SLV

(23) T2074269

COVER, SWINGARM PIVOT

(24) T2081885

RUBBER PAD, SIDESTAND

(25) T2084848

RUBBER PAD, SIDESTAND

(26) T2071077

MOULDING, EDGE, VIN LABEL

(27) T3350003

LOCKNUT, FLANGED, M6 X 1.0

(28) T3013344

FLANGE SLEEVE, 6.4 X 8.8.X.7.5

(29) T3330342

SCREW, PAN/HD, TX, M6 X 35, SLV

	Part number	Description	Qty
# 1	T2074761	FRAME ASSY, WORLD	£2 060,39
# 1	T2074762	FRAME ASSY, AMERICAS	£2 060,39
# 1	T2074763	FRAME ASSY, AUSTRALIA	£2 060,39
# 1	T2074764	FRAME ASSY, CANADA	£2 060,39
# 2	T2071980	ADJUSTER, FRAME, M12	£6,40
# 3	T2051010	SWINGARM PIVOT ADJUSTER	£15,95
# 4	T2071085	CRADLE ASSY, LH	£175,03
# 5	T2071099	CRADLE ASSY, RH	£175,03
# 8	T3150316	BOLT, HHF, M12 X 70, SILVER	£8,57
# 9	T3334675	BOLT, HHF, M12 X 240, SLV	£4,54
# 10	T3501795	WASHER, M12, OD26, HARDENED, SLV	£1,49
# 11	T3350234	LOCKNUT, FLGD, M12 X 1.25	£3,97
# 12	T3050227	SCREW, CAP/HD, M10 X 1.25 X 35, SLV	Not available	£0,00
# 13	T3350250	LOCKNUT, FLANGED, M10	£2,92
# 14	T2075055	BRACKET, M10	£9,86
# 16	T3350219	THREADED INSERT	£2,17
# 18	T3450299	FIRTREE, M6	£2,17
# 19	T2072119	SPACER, 13 X 24 X 29	£4,85
# 20	T2070387	BUNG, RUBBER, OVAL	£2,06
# 21	T3151142	BOLT, TX, M12 X 75, SLV	Not available	£0,00
# 22	T3151141	BOLT, TX, M12 X 55, SLV	£6,46
# 23	T2074269	COVER, SWINGARM PIVOT	£27,86
# 24	T2081885	RUBBER PAD, SIDESTAND	£1,99
# 25	T2084848	RUBBER PAD, SIDESTAND	£1,99
# 26	T2071077	MOULDING, EDGE, VIN LABEL	£10,19
# 27	T3350003	LOCKNUT, FLANGED, M6 X 1.0	£0,62
# 28	T3013344	FLANGE SLEEVE, 6.4 X 8.8.X.7.5	£4,54
# 29	T3330342	SCREW, PAN/HD, TX, M6 X 35, SLV	£1,13

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Triumph, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
