EXHAUST SYSTEM FOR TRIUMPH TIGER 800 XCX

FUEL TANK - FUEL PUMP & FITTINGS

(1) T2200773

HEADER ASSEMBLY, BOLTED

(1) T2201723

HEADER ASSEMBLY, BOLTED

(1) T2201957

HEADER ASSY, BOLTED, BLANK CAT

(1) T2202981

HEADER ASSY, BOLTED

(2) T2200924

PRIMARY HEADER PIPE ASSY

(2) T2201731

PRIMARY HEADER PIPE ASSY

(2) T2201935

PRIMARY HEADER PIPE ASSY, BLANK CAT

(2) T2205145

SILENCER ASSEMBLY, EXHAUST

(3) T2205529

CAT COVER PRESSING

(4) T3330180

SCREW, LGE SKT HD, M5 X 16, S/S

(5) T3010704

SLEEVE, FLANGED, 5.3 X 9 X 6.5

(5) T3010704

SLEEVE, FLANGED, 5.3 X 9 X 6.5

(6) T2204745

GROMMET, SECONDARY CVR BRKT

(7) T3020085

GROMMET, DIA 18X1X9

(7) T3020085

GROMMET, DIA 18X1X9

(8) T3350123

NUT, CAPTIVE, M5, NON-SECURED

(9) T3010708

FLANGED SLEEVE, 8.4 X 12 X 12.5

(10) T3020482

BUSH, RUBBER

(11) T3205486

BOLT, HHF, LGHTD, M8 X 45, SLV

(12) T2202115

GASKET, EXHAUST HEADER

(13) T2206078

CLAMP, EXHAUST, DIA 52-54MM

(14) T2200824

GASKET, HEADER

(15) T2204061

OXYGEN SENSOR, M12

(16) T3350301

NUT, FLANGED, M8, SILVER

(16) T3350301

NUT, FLANGED, M8, SILVER

(17) T2201722

SILENCER ASSY, EXHAUST

(17) T2205145

SILENCER ASSEMBLY, EXHAUST

(18) T2201959

FINISHER, SILENCER, BLACK

(19) T2200622

BUSH, RUBBER, M8

(20) T3010705

FLANGED SLEEVE, 8.4 X 12.4 X 13.8

(20) T3010705

FLANGED SLEEVE, 8.4 X 12.4 X 13.8

(21) T3350004

LOCKNUT, FLANGED, M8 X 1.25

(22) T3350123

NUT, CAPTIVE, M5, NON-SECURED

(23) T3338991

SCREW, BUT/HD, M5 X 20, S/S

(24) T2201719

COVER, SILENCER, ENTRY

(25) T2200929

COVER, SILENCER, EXIT

(26) T3338383

SCREW, PAN/HD, TX, M6 X 12, S/S

(26) T3338383

SCREW, PAN/HD, TX, M6 X 12, S/S

(27) T3202307

BOLT, HHF, M8 X 50, SLV

(28) T2204745

GROMMET, SECONDARY CVR BRKT

(28) T2204745

GROMMET, SECONDARY CVR BRKT

(29) T2205043

FINISHER BOLT, SILENCER

	Part number	Description	Qty
# 1	T2200773	HEADER ASSEMBLY, BOLTED	£856,44
# 1	T2201723	HEADER ASSEMBLY, BOLTED	£893,66
# 1	T2201957	HEADER ASSY, BOLTED, BLANK CAT	£868,84
# 1	T2202981	HEADER ASSY, BOLTED	£875,03
# 2	T2200924	PRIMARY HEADER PIPE ASSY	£819,18
# 2	T2201731	PRIMARY HEADER PIPE ASSY	£893,66
# 2	T2205145	SILENCER ASSEMBLY, EXHAUST	£695,08
# 2	T2201935	PRIMARY HEADER PIPE ASSY, BLANK CAT	Not available	£0,00
# 3	T2205529	CAT COVER PRESSING	£129,10
# 4	T3330180	SCREW, LGE SKT HD, M5 X 16, S/S	£3,66
# 5	T3010704	SLEEVE, FLANGED, 5.3 X 9 X 6.5	£1,43
# 6	T2204745	GROMMET, SECONDARY CVR BRKT	£1,72
# 7	T3020085	GROMMET, DIA 18X1X9	£1,38
# 8	T3350123	NUT, CAPTIVE, M5, NON-SECURED	£1,61
# 9	T3010708	FLANGED SLEEVE, 8.4 X 12 X 12.5	£1,61
# 10	T3020482	BUSH, RUBBER	£2,06
# 11	T3205486	BOLT, HHF, LGHTD, M8 X 45, SLV	Not available	£0,00
# 12	T2202115	GASKET, EXHAUST HEADER	£7,94
# 13	T2206078	CLAMP, EXHAUST, DIA 52-54MM	£13,67
# 14	T2200824	GASKET, HEADER	£5,09
# 15	T2204061	OXYGEN SENSOR, M12	Not available	£0,00
# 16	T3350301	NUT, FLANGED, M8, SILVER	£0,58
# 17	T2201722	SILENCER ASSY, EXHAUST	£695,08
# 17	T2205145	SILENCER ASSEMBLY, EXHAUST	£695,08
# 18	T2201959	FINISHER, SILENCER, BLACK	£161,36
# 19	T2200622	BUSH, RUBBER, M8	£1,49
# 20	T3010705	FLANGED SLEEVE, 8.4 X 12.4 X 13.8	£6,82
# 21	T3350004	LOCKNUT, FLANGED, M8 X 1.25	£1,57
# 22	T3350123	NUT, CAPTIVE, M5, NON-SECURED	£1,61
# 23	T3338991	SCREW, BUT/HD, M5 X 20, S/S	£4,28
# 24	T2201719	COVER, SILENCER, ENTRY	£69,52
# 25	T2200929	COVER, SILENCER, EXIT	£69,52
# 26	T3338383	SCREW, PAN/HD, TX, M6 X 12, S/S	£0,92
# 27	T3202307	BOLT, HHF, M8 X 50, SLV	£4,36
# 28	T2204745	GROMMET, SECONDARY CVR BRKT	£1,72
# 29	T2205043	FINISHER BOLT, SILENCER	£6,52

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the EXHAUST SYSTEM of your Triumph Tiger 800 XCX of 800. Let us know if you have any questions.
