ELECTRICAL EQUIPMENT FOR TRIUMPH TIGER 1050

ENGINE MANAGEMENT SYSTEM

(1) T2500890

MAIN HARNESS

(1) T2500891

MAIN HARNESS

(1) T2501061

MAIN HARNESS

(1) T2507000

MAIN HARNESS

(1) T2507001

MAIN HARNESS

(2) T2506000

RELAY, INDICATOR, 2(4)X10W. 12V

(3) T2501705

RELAY, CHANGEOVER

(4) T2508033

RELAY, EFI

(5) T2500020

BATTERY,12V, 10 AH

(5) T2502347

BATTERY MULTIPACK (10)

(6) T2500113

HORN ASSEMBLY, HI TONE

(7) T3201228

BOLT, HHF, M8 X 14, SLV

(8) T2502405

SWITCH, FALL DETECTION

(9) T3555021

WASHER, 4.3X16.0X1.0

(10) T3330390

SCREW, H/HD, M4 X 25, SLV, ENC

(11) T2501623

LEAD, EARTH AND STARTER

(12) T2501610

LEAD, BATTERY, POSITIVE

(13) T3700015

CABLE TIE, 185.7 LONG

(14) T2501615

FLYLEAD, OIL PRESSURE SWITCH

(15) T2501305

FUSE, MINI, 5A

(16) T2501310

FUSE, MINI, 10A

(17) T2501315

FUSE, MINI, 15A

(18) T2501320

FUSE, MINI, 20A

(19) T2500259

RELAY, GROMMET

(20) T2506025

RELAY, GROMMET

(21) T2506040

RELAY, NORMALLY OPEN, DIODE

(22) T2506045

MOUNT, FUSEBOX

(23) T2501716

LINK LEAD, OXYGEN SENSOR

(24) T2501080

MOULDING, HARNESS COVER

(25) T2102365

BRACKET, HARNESS COVER

(26) T3701170

PLASTIC RIVET, SCREW TYPE

	Part number	Description	Qty
# 1	T2500890	MAIN HARNESS	£552,35
# 1	T2501061	MAIN HARNESS	£552,35
# 1	T2507000	MAIN HARNESS	£552,35
# 1	T2507001	MAIN HARNESS	£552,35
# 1	T2500891	MAIN HARNESS	Not available	£0,00
# 2	T2506000	RELAY, INDICATOR, 2(4)X10W. 12V	£60,22
# 3	T2501705	RELAY, CHANGEOVER	£9,24
# 4	T2502109 T2508033	RELAY, EFI	£25,31
# 5	T2502347	BATTERY MULTIPACK (10)	£802,02
# 5	T2500020	BATTERY, 12V, 10 AH	Not available	£0,00
# 6	T2500113	HORN ASSEMBLY, HI TONE	£27,30
# 7	T3201228	BOLT, HHF, M8 X 14, SLV	£1,80
# 8	T2502405	SWITCH, FALL DETECTION	£55,22
# 9	T3555021	WASHER, 4.3X16.0X1.0	£0,92
# 10	T3330390	SCREW, H/HD, M4 X 25, SLV, ENC	£1,80
# 11	T2501623	LEAD, EARTH AND STARTER	£46,55
# 12	T2501610	LEAD, BATTERY, POSITIVE	£23,88
# 13	T3700015	CABLE TIE, 185.7 LONG	£0,62
# 14	T2501615	FLYLEAD, OIL PRESSURE SWITCH	£7,13
# 15	T2501305	FUSE, MINI, 5A	£3,10
# 16	T2501310	FUSE, MINI, 10A	£3,10
# 17	T2501315	FUSE, MINI, 15A	£3,10
# 18	T2501320	FUSE, MINI, 20A	£3,10
# 19	T2500259	RELAY, GROMMET	£2,69
# 20	T2506025	RELAY, GROMMET	£2,92
# 21	T2506040	RELAY, NORMALLY OPEN, DIODE	Not available	£0,00
# 22	T2506045	MOUNT, FUSEBOX	£18,50
# 23	T2501716	LINK LEAD, OXYGEN SENSOR	£10,72
# 24	T2501080	MOULDING, HARNESS COVER	£6,46
# 25	T2102365	BRACKET, HARNESS COVER	£10,55
# 26	T3701170	PLASTIC RIVET, SCREW TYPE	£0,80

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the ELECTRICAL EQUIPMENT of your Triumph TIGER 1050 of 1050. Let us know if you have any questions.
