REAR BODYWORK & SEAT

SIDE FAIRINGS (FROM 483576) FOR TRIUMPH TIGER 1050

SIDE FAIRINGS (UP TO 483575)

(1) T2306878-CW

COVER PANEL, FUEL TANK, RH

(1) T2306878-LS

COVER PANEL, FUEL TANK, RH

(1) T2306878-NW

COVER PANEL, FUEL TANK, RH

(1) T2306878-PR

COVER PANEL, FUEL TANK, RH

(2) T2306879-CW

COVER PANEL, FUEL TANK, LH

(2) T2306879-LS

COVER PANEL, FUEL TANK, LH

(2) T2306879-NW

COVER PANEL, FUEL TANK, LH

(2) T2306879-PR

COVER PANEL, FUEL TANK, LH

(3) T2306840

SIDEPANEL, RH

(4) T2306841

SIDEPANEL, LH

(5) T3020135

RUBBER GROMMET

(5) T3020135

RUBBER GROMMET

(6) T3660139

SEAL, SEAT LOCK

(7) T3331061

BOLT, BUT/HD, M5 X 11, SHLD, SLV

(7) T3331061

BOLT, BUT/HD, M5 X 11, SHLD, SLV

(7) T3331061

BOLT, BUT/HD, M5 X 11, SHLD, SLV

(7) T3331061

BOLT, BUT/HD, M5 X 11, SHLD, SLV

(8) T3330941

SCREW, BUT/HD, SKT, M5 X 16, SLV

(8) T3330941

SCREW, BUT/HD, SKT, M5 X 16, SLV

(8) T3330941

SCREW, BUT/HD, SKT, M5 X 16, SLV

(8) T3330941

SCREW, BUT/HD, SKT, M5 X 16, SLV

(9) T3350123

NUT, CAPTIVE, M5, NON-SECURED

(9) T3350123

NUT, CAPTIVE, M5, NON-SECURED

(9) T3350123

NUT, CAPTIVE, M5, NON-SECURED

(10) T2306845

COVER, RADIATOR, RHS

(11) T2306846

COVER, RADIATOR, LHS

(12) T3332568

SCREW, BUT/HD, M5 X 8, SLV

(12) T3332568

SCREW, BUT/HD, M5 X 8, SLV

(13) T3660220

RUBBER PAD, 50 X 20 X 5MM

(13) T3660220

RUBBER PAD, 50 X 20 X 5MM

(14) T2303050

BELLYPAN

(15) T2303051

BRACKET, BELLY PAN, RH, FR

(16) T2303052

BRACKET, BELLY PAN, RH, RR

(17) T2303053

BRACKET, BELLY PAN, LH, FR

(18) T2303054

BRACKET, BELLY PAN, LH, RR

(19) T3330848

BOLT, BUT/HD, M6 X 21, SHLD, SLV

(19) T3330848

BOLT, BUT/HD, M6 X 21, SHLD, SLV

(19) T3330848

BOLT, BUT/HD, M6 X 21, SHLD, SLV

(20) T3201228

BOLT, HHF, M8 X 14, SLV

(20) T3201228

BOLT, HHF, M8 X 14, SLV

(21) T3202304

BOLT, RHHF, M6 X 20, SLV

(22) T3450345

CLIP, WIRE, SELF ADHESIVE

(23) T3338989

SCREW, BUT/HD, M5 X 20, S/S

(23) T3338989

SCREW, BUT/HD, M5 X 20, S/S

	Part number	Description	Qty
# 1	T2306878-CW	COVER PANEL, FUEL TANK, RH	£237,43
# 1	T2306878-LS	COVER PANEL, FUEL TANK, RH	£237,43
# 1	T2306878-NW	COVER PANEL, FUEL TANK, RH	£237,43
# 1	T2306878-PR	COVER PANEL, FUEL TANK, RH	£235,82
# 2	T2306879-CW	COVER PANEL, FUEL TANK, LH	£237,43
# 2	T2306879-LS	COVER PANEL, FUEL TANK, LH	£237,43
# 2	T2306879-NW	COVER PANEL, FUEL TANK, LH	£237,43
# 2	T2306879-PR	COVER PANEL, FUEL TANK, LH	£237,43
# 3	T2306840	SIDEPANEL, RH	£67,03
# 4	T2306841	SIDEPANEL, LH	£67,03
# 5	T3020135	RUBBER GROMMET	£1,25
# 6	T3660139	SEAL, SEAT LOCK	£4,28
# 7	T3331061	BOLT, BUT/HD, M5 X 11, SHLD, SLV	£3,28
# 8	T3330941	SCREW, BUT/HD, SKT, M5 X 16, SLV	£4,42
# 9	T3350123	NUT, CAPTIVE, M5, NON-SECURED	£1,61
# 10	T2306845	COVER, RADIATOR, RHS	Not available	£0,00
# 11	T2306846	COVER, RADIATOR, LHS	£45,30
# 12	T3332568	SCREW, BUT/HD, M5 X 8, SLV	£2,54
# 13	T3660220	RUBBER PAD, 50 X 20 X 5MM	£4,66
# 14	T2303050	BELLYPAN	£130,31
# 15	T2303051	BRACKET, BELLY PAN, RH, FR	£10,80
# 16	T2303052	BRACKET, BELLY PAN, RH, RR	£9,91
# 17	T2303053	BRACKET, BELLY PAN, LH, FR	£6,82
# 18	T2303054	BRACKET, BELLY PAN, LH, RR	£9,35
# 19	T3330848	BOLT, BUT/HD, M6 X 21, SHLD, SLV	£3,85
# 20	T3201228	BOLT, HHF, M8 X 14, SLV	£1,80
# 21	T3202304	BOLT, RHHF, M6 X 20, SLV	£3,48
# 22	T3450345	CLIP, WIRE, SELF ADHESIVE	£2,74
# 23	T3338989	SCREW, BUT/HD, M5 X 20, S/S	£4,20

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the SIDE FAIRINGS (FROM 483576) of your Triumph TIGER 1050 of 1050. Let us know if you have any questions.
