EVAPORATIVE LOSS CONTROL SYSTEM - CALIFORNIA ONLY

EXHAUST SYSTEM FOR TRIUMPH TIGER 1050

FUEL TANK - FUEL PUMP & FITTINGS

(1) T2200707

HEADER ASSY, BOLTED

(2) T2200709

EXHAUST HEADER ASSY, NON CAT

(4) T2204745

GROMMET, SECONDARY CVR BRKT

(5) T3020085

GROMMET, DIA 18X1X9

(6) T3010704

SLEEVE, FLANGED, 5.3 X 9 X 6.5

(7) T3330941

SCREW, BUT/HD, SKT, M5 X 16, SLV

(8) T2200702

COVER, CAT HOUSING

(9) T3350123

NUT, CAPTIVE, M5, NON-SECURED

(10) T3350301

NUT, FLANGED, M8, SILVER

(11) T2200326

EXHAUST PIPE SEALING RING

(12) T2204061

OXYGEN SENSOR, M12

(13) T3020482

BUSH, RUBBER

(13) T3020482

BUSH, RUBBER

(14) T3010708

FLANGED SLEEVE, 8.4 X 12 X 12.5

(14) T3010708

FLANGED SLEEVE, 8.4 X 12 X 12.5

(15) T3202307

BOLT, HHF, M8 X 50, SLV

(16) T3350004

LOCKNUT, FLANGED, M8 X 1.25

(17) T2202115

GASKET, EXHAUST HEADER

(18) T2206078

CLAMP, EXHAUST, DIA 52-54MM

(19) T3700000

CLIP, CABLE GUIDE

(20) T3350004

LOCKNUT, FLANGED, M8 X 1.25

(21) T2200386

SILENCER, BOLTED ASSY

(21) T2200866

SILENCER, BOLTED ASSY, BLK

(22) T2200372

SILENCER, NON CAT

(22) T2200867

SILENCER, NON CAT, BLK

(23) T2200374

HEAT SHIELD, SILENCER

(23) T2200868

HEAT SHIELD, BRUSHED, BLK

(24) T3330219

SCREW, SKT HD,SS,M6X12,DIA 17MM

(24) T3330219

SCREW, SKT HD,SS,M6X12,DIA 17MM

(25) T3350102

NUT, CAPTIVE, M5

(25) T3350102

NUT, CAPTIVE, M5

(25) T3350102

NUT, CAPTIVE, M5

(26) T2200451

COVER, SECONDARY SHIELD

(26) T2200869

COVER, SECONDARY, BRUSHED

(27) T3330217

SCREW, M5 X 10, S/S

(28) T3350107

NUT, CAPTIVE, M6

(29) T3205486

BOLT, HHF, LGHTD, M8 X 45, SLV

(30) T3010705

FLANGED SLEEVE, 8.4 X 12.4 X 13.8

(31) T2200622

BUSH, RUBBER, M8

	Part number	Description	Qty
# 1	T2200707	HEADER ASSY, BOLTED	£899,87
# 2	T2200709	EXHAUST HEADER ASSY, NON CAT	£794,36
# 4	T2204745	GROMMET, SECONDARY CVR BRKT	£1,72
# 5	T3020085	GROMMET, DIA 18X1X9	£1,38
# 6	T3010704	SLEEVE, FLANGED, 5.3 X 9 X 6.5	£1,43
# 7	T3330941	SCREW, BUT/HD, SKT, M5 X 16, SLV	£4,42
# 8	T2200702	COVER, CAT HOUSING	£134,05
# 9	T3350123	NUT, CAPTIVE, M5, NON-SECURED	£1,61
# 10	T3350301	NUT, FLANGED, M8, SILVER	£0,58
# 11	T2200326	EXHAUST PIPE SEALING RING	£4,85
# 12	T2204061	OXYGEN SENSOR, M12	Not available	£0,00
# 13	T3020482	BUSH, RUBBER	£2,06
# 14	T3010708	FLANGED SLEEVE, 8.4 X 12 X 12.5	£1,61
# 15	T3202307	BOLT, HHF, M8 X 50, SLV	£4,36
# 16	T3350004	LOCKNUT, FLANGED, M8 X 1.25	£1,57
# 17	T2202115	GASKET, EXHAUST HEADER	£7,94
# 18	T2206078	CLAMP, EXHAUST, DIA 52-54MM	£13,67
# 19	T3700000	CLIP, CABLE GUIDE	Not available	£0,00
# 20	T3350004	LOCKNUT, FLANGED, M8 X 1.25	£1,57
# 21	T2200386	SILENCER, BOLTED ASSY	£657,85
# 21	T2200866	SILENCER, BOLTED ASSY, BLK	£670,25
# 22	T2200372	SILENCER, NON CAT	£570,95
# 22	T2200867	SILENCER, NON CAT, BLK	£583,37
# 23	T2200374	HEAT SHIELD, SILENCER	£161,36
# 23	T2200868	HEAT SHIELD, BRUSHED, BLK	£166,33
# 24	T3330219	SCREW, SKT HD, SS, M6X12, DIA 17MM	£1,06
# 25	T3350102	NUT, CAPTIVE, M5	£1,61
# 26	T2200451	COVER, SECONDARY SHIELD	£48,40
# 26	T2200869	COVER, SECONDARY, BRUSHED	£54,62
# 27	T3330217	SCREW, M5 X 10, S/S	£3,97
# 28	T3350107	NUT, CAPTIVE, M6	£3,28
# 29	T3205486	BOLT, HHF, LGHTD, M8 X 45, SLV	Not available	£0,00
# 30	T3010705	FLANGED SLEEVE, 8.4 X 12.4 X 13.8	£6,82
# 31	T2200622	BUSH, RUBBER, M8	£1,49

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Triumph. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the EXHAUST SYSTEM of your Triumph TIGER 1050 of 1050. Let us know if you have any questions.
